MTI BR181

Beskrivelse

The MTI MPA 82000 is a compact 19″, high power amplifier with a built in eight channel DSP controller.

This unique product is the result of many years of research and development. The design is the result of increasing demands highly influenced by the professional end users. The heavy duty chassis is designed for a “life on the road”.
MPA82000 replaces a typical 12 – 16 unit amplifier system,  including controller, line connector panel and speaker connector panel.
MTI has invested more than three decades of experience in  designing professional audio systems in this extremely sophisticated construction, resulting in considerable advances over traditional amplifier design.  All circuit designs are based on extremely reliable and sophisticated technology, insuring stability into «difficult» loads.
Key features:

• Up to 8 x 500 or 1000W modules in any combination.
• Standard configuration is 4 x 500 Watt and 4 x 1000 Watt modules. 1000 watt modules are bandwidth limited @ 3kHz -1dB. Other configurations on request.
• DSP with full 8 x 8 matrix, EQ, Crossover, Delay, Volume, Limiter.
• Global delay up to 1,6 sec.
• 16 presets available.
• RS485 interface for controlling up to 16 amplifiers by one PC, up to 4000 ft/1200 m.
• Line connector panel.
• Speaker connector panel.
• 3 Unit high.
• 26 kg

Specifications:
Dimensions: 483 x 133 x 620 mm
Rear panel:

• Main power
• Air flow output
• Main fuse

Front panel:

• Standby/On switch
• Air flow input
• Balanced line input
• Speakon output
• Remote IN/OUT

Panel functions:

• 8 x Signal indicator
• 8 x Fault indicator
• 8 x Limiter indicator
• 8 x Character alpha numeric info display

Watt     Load Ohms     Watt RMS    Watt RMS Total
500         8                     250 x 8             2000
500         4                     500 x 8             4000
500         2                     1000* x 8         8000*
1000       8                     500 x 8             4000
1000       4                     1000 x 8           8000
1000       2                     2000* x 8         16000*

*) Burst power

• Ultralow distortion: THD+N < 0.05%, 0.1W – 500W, 10 Hz – 20 kHz, 4 ohms
• Wide dynamic range: 119 dB
• Damping factor: > 800
• Power Supply Rejection Ratio: > 60 dB
